Tengda TD-GPA-LD102 79GHz Barrier Gate Radar
79GHz mmWave barrier radar that distinguishes people from vehicles, 1-6 m detection, IP66.
Description
A 79 GHz FMCW millimetre-wave radar for barrier safety. It distinguishes between people and vehicles and can detect vehicle direction, with a 1-6 m longitudinal detection range and 75 ms response time. IP66 rated, 9-24 VDC supply.
Key facts
- Brand
- Tengda
- Model
- TD-GPA-LD102
- Condition
- New
- Lead time
- 15-30 working days after payment
- Warranty
- 2-year free warranty on all hardware (per Tengda catalogue p.2; not restated in the proforma - confirm in contract)
- Price basis
- EXW Shenzhen, China
Technical specifications
- Transmit frequency
- 79GHz
- Transmit power
- ≤10mW
- Modulation
- FMCW
- Horizontal beam
- -40° to +40°
- Pitch beam
- -15° to +15°
- Antenna
- 2T4R
- Response time
- 75 ms
- Longitudinal detection
- 1-6 m
- Lateral detection width
- -1 m to +1 m
- Vehicle following distance
- ≤0.6 m
- Target type
- Distinguishes people and vehicles
- Arm compatibility
- Universal for 5 m arms (spec); suitable for 8 m straight arms and fence arms (quote description)
- Power supply
- 9-24 VDC
- Operating temperature
- -40°C to +80°C
- Protection
- IP66
